Model #EC-1106-01_052742

Cutaway Allison Transmission – 1000 SERIES

thumbnail

thumbnail

ec1106ima3 (2) (1)

ec1106ima3 (2) (1)

ec1106ima2 (3) (1)

ec1106ima2 (3) (1)

thumbnail
ec1106ima3 (2) (1)
ec1106ima2 (3) (1)

The ConsuLab EC-1106-01 cutaway Allison transmission has been specifically designed for teaching heavy duty automatic transmission theory and operation. It has been strategically sectioned and cutaway to allow students to visualize the internal transmission functions. The Allison 1000 series is a fully automatic torque converter driven, electronically controlled 5-speed automatic transmission that is commonly used in trucks and light vehicles. It has neutral, reverse, and up to 6 forward speeds, with 5th and 6th gears being overdrive.

Pricing upon request

Add to quote list

Description

Educational Advantages

  • Driven by hand crank
  • Allows visualization of gear changes, planetary gear sets, clutches and bands
  • Gear changes can be made using regulated air pressure and provided controls

Application:

  • Allison 1000 Series

Relevant Subjects

  • A2 - Automatic Transmission/Transaxle
  • Automotive Technology

Designed for:

  • High School
  • Industry
  • Technical College

Additional information

Manufacturer

Features

Automotive I Diesel I Hands-On Training I Gear Shift Training I Demonstration of the Seven Different Gear Ratios I Visualization of Gear Changes, Planetary Gear Sets, Clutches and Bands I Transaxle
ASE Categories

A2
Facility Requirements

120 VAC, Required Shop Air Supply

Product Documents

Cutaway Allison Transmission - 1000 SERIES

Size Chart

  • Trainer Dimensions: 60" x 33" x 59" inches
  • Trainer Weight: 690 lbs
  • Shipping Dimensions: 64" x 36" x 60" inches
  • Shipping Weight: 775 lbs
