ELECTUDE Courseware for Speed and Position Sensors Trainer

ELECTUDE Courseware for Speed and Position Sensors Trainer

ELECTUDE Courseware for Speed and Position Sensors Trainer

Model #E-EM-200-25_052984

ELECTUDE Courseware for Speed and Position Sensors Trainer

The perfect eLearning complement to ConsuLab’s Speed and Position Sensors Trainer, ELECTUDE’s courseware consists of 8 student-led practical assignments and over 9.5 hours of instruction.

Learners develop diagnostic skills using this blended e-learning and mechanical training aid package.  The combination of Electude’s e-learning modules with ConsuLab’s tabletop sensors training system creates a dynamic, hands-on environment for every level of learner. The package covers some of the most common analog and digital sensors, including hall effect and magneto resistance.

With this practical set-up, the participant can supplement previously acquired knowledge of sensors with practical skills. The practical set-up contains four sensors for determining speed and position; inductive, Hall, MRE with internal and MRE with external magnet.

Check Out the FREE Demo Under “Software Package”

Pricing upon request

Software package

Want to check out a demo of ELECTUDE’s eLearning for the EM-200-25?

Demo ELECTUDE CL-1919-05

Description

The perfect eLearning complement to ConsuLab’s Speed and Position Sensors Trainer, ELECTUDE’s courseware consists of 8 student-led practical assignments and over 9.5 hours of instruction.

With this practical set-up, the participant can supplement previously acquired knowledge of sensors with practical skills. The practical set-up contains four sensors for determining speed and position; inductive, Hall, MRE with internal and MRE with external magnet.

EM-200-25 Topics of Coverage

Through the preparatory theory and practical assignments the student learns:

  •  How to manage the multimeter and oscilloscope.
  • Concepts such as amplitude, frequency and pulse width modulation.
  • Which checks apply to the relevant sensor with multimeter and oscilloscope .
  • To recognize and analyze voltages and signals.
  • What effect speed, sensor wheel shape, air gap, resistance in cabling have on the signal.
  • What this effect on the signal can mean for the functioning of the vehicle and therefore for the customer.

Learning Topics

  • Automotive Technology
  • eLearning

Grade/Skill Level

Designed for:

  • High School
  • Industry
  • K-8
  • Technical College
  • University

Additional information

Manufacturer

,

ASE Categories

A6

Features

eLearning, Student-Paced Learning, Hybrid Classroom, Remote Learning, Skills-based, inexpensive curriculum, LMS
